DISRUPT CAD I CE Mark Study

A single-arm, pre-market study demonstrating the safety and performance of Shockwave Intravascular Lithotripsy (IVL) in heavily calcified, coronary lesions prior to stenting and followed to 6 months; also included an OCT sub-study demonstrating Shockwave IVL’s mechanism of action.

Study Leadership

Jean Fajadet, MD

Clinical Pasteur, Toulouse, France
Prof. Carlo Di Mario

AOU Careggi SOD Interventistica, Firenze, Italy

60

Patients
7

European sites
100

%

Severe calcified lesions
6

Month follow-up

Study Design and Patient Characteristics

Objective

A single-arm, pre-market study demonstrating the safety and performance of Shockwave IVL in heavily calcified, coronary lesions prior to stenting and followed to 6 months; also included an OCT sub-study demonstrating Shockwave IVL’s mechanism of action.

Primary Safety Endpoint

30-day major adverse cardiovascular event (MACE)

Secondary Performance Endpoint

<50% residual stenosis post-percutaneous coronary intervention (PCI) with no evidence of in-hospital MACE

Patient Characteristics Summary

Stable angina, unstable angina or silent ischemia
Moderate and severely calcified, de novo coronary lesions right ventricular systolic dysfunction (RVD) 2.5 – 4.0 mm, stenosis ≥50%, lesion length ≤32 mm

100% severe calcified lesions 

95% clinical success; 98.3% device success & Shockwave IVL treatment at target lesion; 100% stent delivery

Countries Included in Study

Australia
France
Netherlands
Sweden
United Kingdom

Strong Safety and Low Complications

Safety	Results	Events
30-day MACE* cardiac death, myocardial infarction (MI) or tricuspid valve replacement (TVR)	5%	Cardiac death N = 0 QWMI N = 0 **NQWMI N = 3 TVR N = 0
6-month MACE* cardiac death, myocardial infarction (MI) or tricuspid valve replacement (TVR)	8.3%	Cardiac death N = 2 QWMI N = 0 **NQWMI N = 3 TVR N = 0

Core lab adjudicated
*CEC adjudicated
**NQMI defined as 3x upper limit CK-MB

Complications	Procedural	Final
Dissection (D / E / F)	3.3% / 0% / 0%	0% / 0% / 0%
Perforation	0.0%	0.0%
Abrupt closure	0.0%	0.0%
Slow flow	0.0%	0.0%
No reflow	0.0%	0.0%

Brinton et al 2019 in Circ Int.

DISRUPT CAD I OCT Sub-Study Confirms Mechanism of Action (MOA) of Shockwave Intravascular Lithotripsy

31

Patients
3

OCT runs: Baseline, post-IVL & post-stent
55%

Fracture post-stent
2.1 mm

²

Acute area gain post-IVL
5.9 mm

²

Minimal stent area

Read the full DISRUPT CAD I OCT sub-analysis on the JACC: Cardiovascular Imaging website:

Read the Analysis

OCT Sub-Analysis Key Findings

Transmural fractures: Shockwave IVL shown to fracture both intimal and medial calcium under OCT
More fractures: The more severe the calcium, the greater the incidence of fracture
Improved compliance: Improved vessel compliance enables similar stent expansion across all lesions, despite calcium severity

Frames are co-registered to ensure cross-sections are in the same location.
